    6x4 371hp 16CBM 18CBM Compressed Garbage Truck

    Ask Lasest Price
    Brand Name : SINOTRUK HOWO
    Model Number : ZZ3257M3841
    Certification : ISO/3C/BV/IFA/SGS
    Price : US$45000-US$60000/unit
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 2000 units per month
    Delivery Time : 30-35 working days after deposit or LC
    • Product Details
    • Company Profile

    6x4 371hp 16CBM 18CBM Compressed Garbage Truck

    Refuse Compactor Truck Sinotruk HOWO 6x4 371hp 16CBM 18CBM Garbage Compactor Truck Compressed Garbage Truck


    SINOTRUK HOWO Refuse Compactor Truck, the best choice for you!


    Our refuse compactors (waste compactors) are widely used to compact household garbage, commercial wastes and industrial refuse of nonhazardous and with no rusty and no radioactivity.


    With payloads of 3—15 tons, the machine is designed with both hand and automatic controls system with the specialties of large volume, high efficiency, better sealing and easy for service so that they are widely used in municipal refuse handling, commercial and industrial garbage operations.


    6x4 371hp 16CBM 18CBM Compressed Garbage Truck6x4 371hp 16CBM 18CBM Compressed Garbage Truck

    6x4 371hp 16CBM 18CBM Compressed Garbage Truck6x4 371hp 16CBM 18CBM Compressed Garbage Truck6x4 371hp 16CBM 18CBM Compressed Garbage Truck6x4 371hp 16CBM 18CBM Compressed Garbage Truck6x4 371hp 16CBM 18CBM Compressed Garbage Truck



    The parameter of Sinotruk HOWO 6x4 371hp 16CBM 18CBM 16M3 18M3 garbage compactor truck compressed garbage truck:

    Item No.Parameters
    Overall Dimension10290x2496x3270 mm
    Gross Vehicle Weight25000 kg
    Curb weight13650 kg
    Loading capacity16000-20000 kg
    Wheel Base4600+1350
    Front axle loading capacityHF9, 1x9000 kg
    Rear axle loading capacityST16, 2x16000 kg
    Max Driving Speed75 km/h
    EngineWD615.87, 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
    Engine horsepower290 HP
    Emission StandardEuro II
    Displacement9.726L
    Gear BoxHW19710, 10 Forwards gear & 2 reverse gear
    Steering GearZF 8098, power steering, hydraulic steering with power assistance
    ClutchReinforced diaphragm clutch, diameter 430mm
    Fuel Tank400L Aluminum alloy fuel tank
    CabinHOWO 76 Standard Cab, RHD, Right Hand Drive; Two seats with 1 sleeper, with air conditioner, 70° hydraulically tillable to the front.
    Tire12R22.5 Tubeless Tire , 10 pieces with one spare
    Brake

    Service brake: dual circuit compressed air brake

    Parking brake: spring energy, compressed air operating on rear wheels

    Auxiliary brake: engine exhaust valve brake

    Equipment

    1. Garbage body: 20m3.

    2,Equipped with hermetic dustbin, hydraulic system and operating system

    3, Automatic compress and uninstall, sewage can be collected by the dump tank.

    4. Cycling time<14--18s




    1. The hydraulic system adopted double-pump double-loop structure which avoided system heating phenomenon and thus reduced power dissipation.
    2. The garbage truck adopts both manual and automatic hydraulic control system;
    3. L-type sealing ribbon and hydraulic locking device is adopted and thus effectively guaranteed the sealing between the feeding machine and the carriage and avoided sewage leaking;
    4. High compression ratio for the wastes are compressed by two sides;
    5. Fuel saving: While feeding wastes, the motor will accelerate synchronously;
    6. Stable operation and low noise.


    By Roro or Bulk or Flat Rack Container according to your specific requests.



    1, the whole truck warrenty is 1 year or 50000km, base on whichever comes first.

    2, professional sevice team, enough spare parts to make you away from future worries.

    3, professional trainning teachers for your drivers or engineers on repair and maintenance
